Technical data H1680T-A H16100T-A
Load rating 80 W 100 W
Nominal impedance 16 ohms 16 ohms
Transformer tappings 80-40-20 W (100V) 100-50-25 W (100V)
80-40-30-10W (70V) 100-50-25-12.5W (70V)
Frequency range 400Hz-5KHz 400Hz-5KHz
SPL(@1W/m) 105 dB 105 dB
Protection type IP 66 IP 66
Dimension Ø*D(mm) Ø405*420mm Ø405*420mm
Weight
Material,Colour Alu / grey Alu / grey
